Kubernetes 1.24 Ubuntu18.04安装

集群清单

一、初始化设置（所有节点都需执行）

1、配置静态IP

#下载网络工具
sudo apt-get install network-manager

# 记住网卡名称
ifconfig

# 记住网关地址
netstat -rn

打开vi /etc/netplan/00-installer-config.yaml文件，进行如下配置

network:
  renderer: NetworkManager
  ethernets:
    ens33:
      dhcp4: false
      dhcp6: false
      addresses: [192.168.56.130/24]	# 本机IP/掩码
      gateway4: 192.168.56.2		# 网关
      nameservers:
        addresses: [8.8.8.8]		# DNS地址，和网关一致，也能使用8.8.8.8或者144.144.144.144
  version: 2

配置完成后对其进行更新，并测试

# 应用更改
netplan apply

# 测试是否成功
ping www.baidu.com（如果不通，再执行一次netplan apply，或者更改DNS）

2、设置时区

# 设置时区
timedatectl set-timezone Asia/Shanghai

# 设置校时服务
apt-get install ntpdate
ntpdate ntp.aliyun.com

3、关闭Selinux（Ubuntu默认没有安装，可跳过）

setenforce 0
sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config

4、关闭swap（k8s官方不支持swap）

swapoff -a
sed -i 's/.*swap.*/#&/' /etc/fstab
free -m

5、设置主机名

cat /etc/hostname << EOF
192.168.56.130 master
192.168.56.129 node
EOF

6、将桥接的 IPv4 流量传递到 iptables

cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF
sysctl --system

7、关闭防火墙

apt-get install iptables
ufw disable
sysctl --system

二、安装Container

1、下载apt仓库所需包

# 更新apt包
apt-get update

# 安装
apt-get -y install apt-transport-https ca-certificates curl software-properties-common

2、安装密钥

curl -fsSL https://mirrors.aliyun.com/docker-ce/linux/ubuntu/gpg | sudo apt-key add -

3、添加存储库

add-apt-repository "deb [arch=amd64] https://mirrors.aliyun.com/docker-ce/linux/ubuntu $(lsb_release -cs) stable"

4、更新，安装docker-ce

# 更新
apt-get -y update

# 安装docker-ce
apt-get -y install docker-ce

6、创建配置并启动

mkdir /etc/docker
# Setup daemon.
cat > /etc/docker/daemon.json <<EOF
{
  "exec-opts": ["native.cgroupdriver=systemd"],
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "100m"
  },
  "registry-mirrors": ["https://e6vlzg9v.mirror.aliyuncs.com"]
}
EOF

mkdir -p /etc/systemd/system/docker.service.d
chmod 777 /var/run/docker.sock
sed -i   '/^disabled_plugins/d' /etc/containerd/config.toml
systemctl restart containerd
systemctl daemon-reload && service docker start && systemctl enable docker
docker ps

cat <<EOF> /etc/crictl.yaml
runtime-endpoint: unix:///run/containerd/containerd.sock
image-endpoint: unix:///run/containerd/containerd.sock
timeout: 10
debug: false
EOF

systemctl restart containerd
systemctl daemon-reload && service docker start && systemctl enable docke
crictl images

三、安装Kubernetes三剑客（kubelet、kubeadm、kubectl）

1、更新包并下载apt-transport-https

apt-get update && apt-get install -y apt-transport-https

2、配置镜像源并更新

sudo curl https://mirrors.aliyun.com/kubernetes/apt/doc/apt-key.gpg | apt-key add -

cat <<EOF >/etc/apt/sources.list.d/kubernetes.list
deb https://mirrors.aliyun.com/kubernetes/apt/ kubernetes-xenial main
EOF
apt-get update

3、安装指定版本的三剑客

apt-get install -y kubelet=1.24.0-00 kubeadm=1.24.0-00 kubectl=1.24.0-00

4、设置开机自，启动并查看状态

systemctl enable kubelet && systemctl start kubelet && systemctl status kubelet

四、初始化集群

        由于v1.24 版本的k8s 使用的是containerd。 docker load 和 ctr images import 都无效。所以通过手动拉取镜像的方式拉取所需镜像。（每台都执行）

crictl pull docker.io/calico/cni:v3.24.0
crictl pull docker.io/calico/kube-controllers:v3.24.0
crictl pull docker.io/calico/node:v3.24.0
crictl pull docker.io/library/nginx:latest
crictl pull registry.aliyuncs.com/google_containers/pause:3.6
crictl pull registry.aliyuncs.com/google_containers/coredns:v1.8.6
crictl pull registry.aliyuncs.com/google_containers/etcd:3.5.3-0
crictl pull registry.aliyuncs.com/google_containers/kube-apiserver:v1.24.0
crictl pull registry.aliyuncs.com/google_containers/kube-controller-manager:v1.24.0
crictl pull registry.aliyuncs.com/google_containers/kube-proxy:v1.24.0
crictl pull registry.aliyuncs.com/google_containers/kube-scheduler:v1.24.0
crictl pull registry.aliyuncs.com/google_containers/pause:3.7

ctr -n k8s.io i tag registry.aliyuncs.com/google_containers/pause:3.6 k8s.gcr.io/pause:3.6

1、配置Master节点

（1）初始化集群

sudo kubeadm init --image-repository=registry.aliyuncs.com/google_containers --pod-network-cidr=10.244.0.0/16 --kubernetes-version=v1.24.0 --ignore-preflight-errors=all -v5

（2）文件创建

  sudo mkdir -p $HOME/.kube

  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config

  sudo chown $(id -u):$(id -g) $HOME/.kube/config

（3）写入配置

echo "export KUBECONFIG=/etc/kubernetes/admin.conf" >> /etc/profile
source /etc/profile

（4）将admin.conf拷贝到其他节点的指定目录下

scp /etc/kubernetes/admin.conf user:xxx.xxx.xxx.xxx:/etc/kubernetes/

2、配置Node节点

（1）确认admin.conf已经拷贝到指定目录，并拥有足够权限，写入配置

ll /etc/kubernetes/admin.conf

echo "export KUBECONFIG=/etc/kubernetes/admin.conf" >> /etc/profile

（2）执行Master集群初始化后的命令，如果忘记可以在Master节点上执行“sudo kubeadm token create --print-join-command”命令，然后将输出复制到Node节点执行

sudo kubeadm join xxx --token xxxxx --discovery-token-ca-cert-hash sha256:xxxx -v 5

五、安装网络插件（Master上执行）

sudo curl https://docs.projectcalico.org/manifests/calico.yaml -O && kubectl apply -f calico.yaml

六、部署测试应用

1、在Master上执行kubectl get node，当Status显示为Ready时再执行下面语句，创建tomcat服务。

kubectl create deployment  tomcat --image=tomcat

kubectl  expose deployment tomcat  --port=8080 --target-port=8080 --type=NodePort

2、执行“kubectl get pods”命令，当Status为Running且Ready为1/1时执行下面命令，确认端口为31423

# 找到端口号
root@master:~# kubectl get service
NAME         TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)          AGE
kubernetes   ClusterIP   10.96.0.1       <none>        443/TCP          34m
tomcat       NodePort    10.108.160.28   <none>        8080:31423/TCP   30m

3、在网页输入cluster IP+service port，进行访问。出现如下页面，则集群搭建成功
