巨元中心包含了企业的全部核心应用。其一般由有线网络接入（带有固定公网IP地址）、支持VPN接入的防火墙，路由器，及维护人员组成。
作为管理人员可通过人工方式，或企业已有的应用服务，对工程现场的设备进行维护或监控。
出差维护工程师：
身处异地的维护工程师会由于多种原因参与到远程的客户支持中。维护工程师可以接入Internet，通过巨元监控中心的安全认证，与客户现场的设备建立连接。基于东用科技《无线远程维护解决方案》，巨元可获得满足以下特征的完美系统：
工程现场网络无人值守，4G无线工业路由器7*24小时在线。
4G无线工业路由器无需另购开关电源，可通过PLC电源直接供电。
工程现场网络接入无需运营商布线，4G无线工业路由器通过遍布全球的4G网络快速接入Internet。
4G无线工业路由器集成多层次安全功能，用户无需另购其他网络安全设备。
提高人力资源的利用率：巨元维护人员可通过安全隧道，对现场故障工程进行分析，如可远程解决则避免维修工程师往复故障现场。如不可解决则安排配件及附近工程师排除此故障。
提升企业形象，创造二次价值：巨元可利用已有业务系统，实时搜集前端设备状态。如发现前端设备呈现故障特征，提早安排对此设备进行维护。这样既可大大降低设备的停机率，提升产品可靠性。又可提升企业在用户心中的形象，降低企业维修成本，为巨元在未来行业竞争中赢得高端市场提供充足的实力。PLC
带有以太网接口，能够配置IP地址及网关。
orb305：
连接4G/5G网络并与中心端接入路由器建立VPN连接，使中心端能够与下端PLC通讯，并对其进行监控和编程管理。
UIM/SIM卡：
用于4G/5G路由器（ORB305）拨号到运营商网络。
（2）监控中心端： VPN路由器：
用于中心监控室接入网络，并与下端ORB305无线路由器建立VPN连接，管理下端4G/5G路由器，还可以提供办公上网。
企业宽带接入：
使用中国电信、中国联通提供的企业宽带，或者商用ADSL（需包含公网IP地址）。
PC/服务器：
只要满足能够运行监控软件运行即可。
中心监控软件：
监控软件，主要用于采集下端PLC数据，控制相应的设备。
PLC编程软件：
用于初始化及更改PLC程序。
四、方案产品
ORB305无线路由器
DIN导轨安装，工业级无线路由器
ORB305无线路由器，是一款支持DIN导轨安装的工业无线路由器，采用4G高速无线网络作为数据承载网络，为远程设备和站点之间的联网提供安全高速的无线连接。无论身在何处，您的设备都可以借助4G/5G网络快速接入互联网。ORB305无线路由器满足工业用户的需求，功耗低，操作温度可达-40℃~70℃，尺寸小，重量轻，支持DIN导轨安装，EMC指标严格，便于应用在严苛、狭小的工业环境中，是工业应用的理想选择。
ORB305无线路由器同时具有VPN功能，使设备数据在安全的IPSec隧道中传输，防止了数据被访问和篡改，提供了网络应用更高的安全性。 ORB305工业路由器特点：
高可靠性网络功能
采用高性能通讯模块，快速接入4G/5G网络；
采用软硬件看门狗及多级链路检测机制，具备故障自动检测、自动恢复能力，保证设备稳定可靠运行；
远程和本地升级固件程序，且采用冗余备份的升级机制；
易用性
丰富的接口，赋予设备高扩展性；
支持WEB、TELNET、SSH等多种配置方式；
支持配置导入导出功能，方便批量设备的配置工作；
支持软、硬件恢复出厂设置；
具备无线网络信号指示灯，分三级显示现场信号强度；
网络接口10M/100M自适应，交叉直连自适应；
支持DMZ；
支持DTU功能，赋予串口设备无线传输能力；
网络安全
虚拟专用网（VPN），支持基于标准IPSec的VPN服务；
全状态包检测（SPI）和拒绝服务（DoS）攻击防范等防火墙安全性能，在决定什么样的数据包允许通过之前，SPI检测所有进入数据包的头部内容。过滤器能被设置成为基于MAC地址或IP地址；
采用合法的MAC地址，每台硬件设备的网卡MAC地址全球唯一，避免局域网内MAC地址冲突；
支持集中式网管的能力，可通过网管平台支持大量设备的集中管理、批量配置和升级功能；
针对工业应用的设计
工业化设计，产品外壳具有足够的机械强度和刚度，标准工业DIN导轨式安装，适用于工业机柜安装；
SIM卡提供拆卸保护；
Juyuan center contains all core applications of the enterprise. It is generally composed of wired network access (with fixed public network IP address), firewall supporting VPN access, router, and maintenance personnel.
As a manager, you can maintain or monitor the equipment on the project site manually or through the existing application services of the enterprise.
Travel maintenance engineer:
Maintenance engineers in different places will participate in remote customer support for a variety of reasons. The maintenance engineer can access the Internet and establish a connection with the equipment on the customer's site through the security authentication of Juyuan monitoring center. Based on Dongyong technology's wireless remote maintenance solution, Juyuan can obtain a perfect system that meets the following characteristics:
The project site network is unattended, and the 4G wireless industrial router is online 7 * 24 hours.
4G wireless industrial router does not need to buy a separate switching power supply, and can be directly powered by PLC power supply.
The network access at the project site does not require operator wiring, and 4G wireless industrial routers quickly access the Internet through 4G networks all over the world.
4G wireless industrial router integrates multi-level security functions, and users do not need to purchase other network security equipment.
Improve the utilization rate of human resources: Juyuan maintenance personnel can analyze the on-site fault engineering through the safety tunnel. If it can be solved remotely, maintenance engineers can be prevented from going back and forth to the fault site. If it cannot be solved, arrange accessories and nearby engineers to eliminate the fault.
Improve the corporate image and create secondary value: Juyuan can collect the status of front-end equipment in real time by using the existing business system. If it is found that the front-end equipment shows fault characteristics, the maintenance of this equipment shall be arranged in advance. In this way, the downtime of the equipment can be greatly reduced and the reliability of the product can be improved. It can also improve the image of the enterprise in the hearts of users, reduce the maintenance cost of the enterprise, and provide sufficient strength for Juyuan to win the high-end market in the future industry competition. PLC
With Ethernet interface, IP address and gateway can be configured.
orb305：
Connect the 4G / 5G network and establish VPN connection with the central end access router, so that the central end can communicate with the lower end PLC, monitor and program it.
UIM / SIM card:
It is used for 4G / 5G router (orb305) dialing to operator network.
(2) Monitoring center end: VPN Router:
It is used for the central monitoring room to access the network, establish VPN connection with the lower end orb305 wireless router, manage the lower end 4G / 5G router, and provide office Internet access.
Enterprise broadband access:
Use enterprise broadband provided by China Telecom and China Unicom, or commercial ADSL (including public network IP address).
PC / Server:
As long as the monitoring software can be run.
Central monitoring software:
The monitoring software is mainly used to collect the lower end PLC data and control the corresponding equipment.
PLC programming software:
Used to initialize and change PLC programs.
4、 Program product
Orb305 wireless router
DIN rail mounting, industrial wireless router
Orb305 wireless router is an industrial wireless router that supports DIN rail installation. It uses 4G high-speed wireless network as the data carrying network to provide safe and high-speed wireless connection for networking between remote devices and stations. Wherever you are, your device can quickly access the Internet with the help of 4G / 5G networks. Orb305 wireless router meets the needs of industrial users, with low power consumption, operating temperature of - 40 ℃ ~ 70 ℃, small size, light weight, support for DIN rail installation, strict EMC index, easy to apply in harsh and narrow industrial environment, and is an ideal choice for industrial applications.
Orb305 wireless router also has VPN function, so that device data is transmitted in a secure IPSec tunnel, preventing data from being accessed and tampered with, and providing higher security for network applications. Orb305 industrial router features:
High reliability network function
Adopt high-performance communication module to quickly access 4G / 5G network;
It adopts software and hardware watchdog and multi-level link detection mechanism, with the ability of automatic fault detection and automatic recovery to ensure the stable and reliable operation of the equipment;
Upgrade firmware programs remotely and locally, and adopt the upgrade mechanism of redundant backup;
Ease of use
Rich interfaces give the device high scalability;
Support web, Telnet, SSH and other configuration modes;
Support configuration import and export functions to facilitate the configuration of batch devices;
Support software and hardware recovery to factory settings;
Equipped with wireless network signal indicator, which displays the field signal strength in three levels;
Network interface 10m / 100M adaptive, cross direct connection adaptive;
Support DMZ;
Support DTU function and give the serial port device wireless transmission capability;
network security
Virtual private network (VPN), supporting VPN service based on standard IPSec;
Full state packet detection (SPI) and denial of service (DOS) attack prevention and other firewall security features. SPI detects the header contents of all incoming packets before deciding what kind of packets are allowed to pass. The filter can be set based on a MAC address or an IP address;
Legal MAC address is adopted, and the MAC address of the network card of each hardware device is unique in the world to avoid MAC address conflict in the LAN;
Support the centralized network management capability, and support the centralized management, batch configuration and upgrade functions of a large number of devices through the network management platform;
Design for industrial applications
Industrial design, the product shell has sufficient mechanical strength and rigidity, Standard Industrial DIN rail type installation, suitable for industrial cabinet installation;
The SIM card provides disassembly protection;
