（eNSP）通过配置MQC与NQA联动保障流量正常转发-EW帮帮网

1.实验拓扑

2.实验配置

<SW1>dis cu
#
sysname SW1
#
vlan batch 2 10 30
#
dhcp enable
#
interface Vlanif2
 ip address 10.1.1.2 255.255.255.0
#
interface Vlanif10
 ip address 192.168.10.253 255.255.255.0
 dhcp select interface
 dhcp server excluded-ip-address 192.168.10.254
#
interface Vlanif30
 ip address 192.168.30.254 255.255.255.0
 dhcp select interface
#
interface GigabitEthernet0/0/1
 port link-type access
 port default vlan 2
#
interface GigabitEthernet0/0/2
 port link-type access
 port default vlan 10
#
interface GigabitEthernet0/0/3
 port link-type access
 port default vlan 30
#
ospf 1
 area 0.0.0.0
  network 192.168.10.0 0.0.0.255
  network 192.168.30.0 0.0.0.255
  network 10.1.1.0 0.0.0.255
#

<SW2>dis cu
#
sysname SW2
#
vlan batch 20
#
dhcp enable
#
interface Vlanif20
 ip address 192.168.20.253 255.255.255.0
 dhcp select interface
 dhcp server excluded-ip-address 192.168.20.254
#
interface GigabitEthernet0/0/1
 port link-type access
 port default vlan 20
#
interface GigabitEthernet0/0/2
 port link-type access
 port default vlan 20
#
ospf 1
 area 0.0.0.0
  network 192.168.20.0 0.0.0.255
#

<R1>dis cu
[V200R003C00]
#
 sysname R1
#
acl number 3000
 rule 5 permit ip source 192.168.10.0 0.0.0.255 destination 192.168.20.0 0.0.0.2
55
acl number 3010
 rule 5 permit ip source 192.168.30.0 0.0.0.255 destination 192.168.20.0 0.0.0.2
55
#
traffic classifier yidong operator or
 if-match acl 3010
traffic classifier dianxin operator or
 if-match acl 3000
#
traffic behavior yidong
 redirect ip-nexthop 13.1.1.3 track nqa 13 34
traffic behavior dianxin
 redirect ip-nexthop 12.1.1.2 track nqa 12 24
#
traffic policy chukou
 classifier dianxin behavior dianxin
 classifier yidong behavior yidong
#
interface GigabitEthernet0/0/0
 ip address 12.1.1.1 255.255.255.0
#
interface GigabitEthernet0/0/1
 ip address 13.1.1.1 255.255.255.0
#
interface GigabitEthernet0/0/2
 ip address 10.1.1.1 255.255.255.0
 traffic-policy chukou inbound
#
ospf 1
 default-route-advertise
 area 0.0.0.0
  network 10.1.1.0 0.0.0.255
#
ip route-static 0.0.0.0 0.0.0.0 12.1.1.2
ip route-static 0.0.0.0 0.0.0.0 13.1.1.3
#
nqa test-instance 12 24
 test-type icmp
 destination-address ipv4 24.1.1.4
 frequency 5
 probe-count 1
 start now
nqa test-instance 13 34
 test-type icmp
 destination-address ipv4 34.1.1.4
 frequency 5
 probe-count 1
 start now
#

<R4>dis cu
[V200R003C00]
#
 sysname R4
#
acl number 3000
 rule 5 permit ip source 192.168.20.0 0.0.0.255 destination 192.168.10.0 0.0.0.2
55
acl number 3010
 rule 5 permit ip source 192.168.20.0 0.0.0.255 destination 192.168.30.0 0.0.0.2
55
#
traffic classifier yidong operator or
 if-match acl 3010
traffic classifier dianxin operator or
 if-match acl 3000
#
traffic behavior yidong
 redirect ip-nexthop 34.1.1.3 track nqa 34 13
traffic behavior dianxin
 redirect ip-nexthop 24.1.1.2 track nqa 24 12
#
traffic policy chukou
 classifier dianxin behavior dianxin
 classifier yidong behavior yidong
#
interface GigabitEthernet0/0/0
 ip address 34.1.1.4 255.255.255.0
#
interface GigabitEthernet0/0/1
 ip address 24.1.1.4 255.255.255.0
#
interface GigabitEthernet0/0/2
 ip address 192.168.20.254 255.255.255.0
 traffic-policy chukou inbound
#
ospf 1
 default-route-advertise
 area 0.0.0.0
  network 192.168.20.0 0.0.0.255
#
ip route-static 0.0.0.0 0.0.0.0 24.1.1.2
ip route-static 0.0.0.0 0.0.0.0 34.1.1.3
#
nqa test-instance 24 12
 test-type icmp
 destination-address ipv4 12.1.1.1
 frequency 5
 probe-count 1
 start now
nqa test-instance 34 13
 test-type icmp
 destination-address ipv4 13.1.1.1
 frequency 5
 probe-count 1
 start now
#

<R2>dis cu
[V200R003C00]
#
 sysname R2
#
interface GigabitEthernet0/0/0
 ip address 24.1.1.2 255.255.255.0
#
interface GigabitEthernet0/0/1
 ip address 12.1.1.2 255.255.255.0
#
ip route-static 192.168.10.0 255.255.255.0 12.1.1.1
ip route-static 192.168.20.0 255.255.255.0 24.1.1.4
ip route-static 192.168.30.0 255.255.255.0 12.1.1.1
#

<R3>dis cu
[V200R003C00]
#
 sysname R3
#
interface GigabitEthernet0/0/0
 ip address 13.1.1.3 255.255.255.0
#
interface GigabitEthernet0/0/1
 ip address 34.1.1.3 255.255.255.0
#
ip route-static 192.168.10.0 255.255.255.0 13.1.1.1
ip route-static 192.168.20.0 255.255.255.0 34.1.1.4
ip route-static 192.168.30.0 255.255.255.0 13.1.1.1
#
