内容摘要:
本文介绍了在Vue3中使用vxe-table插件实现可编辑表格的封装方案。通过两个示例展示了不同表头结构的实现:第一个表格采用单级表头,包含合并单元格和可编辑功能;第二个表格实现多级表头结构,包含子表头和单元格编辑控制。代码中通过reactive定义表格数据和配置,使用pointExists方法控制可编辑单元格范围,并提供了样式自定义。这种封装方式相比原生element组件能更好地支持复杂表格需求。
背景:
在vue3项目中,根据客户的需求,需要实现不同的表格并且表格要可以编辑。可编辑表格,有点像form表单,要实现可以在表格中输入数据,table的壳子,form的业务。使用element组件实现效果不太好实现,根据百度找到了这个插件vxe-table。
安装的版本号分别是:
"vxe-pc-ui": "^4.7.14",
"vxe-table": "^4.14.4",
这里封装了一个示例,包括二级表头、多级表头的封装。
参考博文:点击跳转
实现效果:
直接复制代码看一下效果吧。。。
完整代码:
<template>
<div>
<div class="container1 infoState">
<vxe-table :data="infoState.tableData" empty-text="没有更多数据了!" :loading="infoState.loading" :border="'full'"
:align="'center'" :merge-cells="infoState.mergeCells" :edit-config="infoState.editConfig">
<vxe-colgroup title="船舶信息" :header-cell-class-name="'header-cell'">
<vxe-column v-for="(item, index) in infoState.tableList" :field="item.prop" :title="item.label"
:width="item.width" :key="index" :edit-render="{ name: 'VxeInput' }"></vxe-column>
</vxe-colgroup>
</vxe-table>
</div>
<div class="container1 incomeState">
<vxe-table :data="incomeState.tableData" empty-text="没有更多数据了!" :loading="incomeState.loading"
:border="'full'" :align="'center'" :merge-cells="incomeState.mergeCells"
:edit-config="incomeState.editConfig">
<vxe-colgroup title="航次收入" :header-cell-class-name="'header-cell'">
<template v-for="(item, index) in incomeState.tableList" :key="index">
<vxe-column :field="item.prop" :title="item.label" :width="item.width" v-if="!item.children"
:edit-render="{ name: 'VxeInput', placeholder: '请点击输入...' }"></vxe-column>
<vxe-colgroup v-else :title="item.label" :header-cell-class-name="'header-cell'">
<vxe-column v-for="(item2, index2) in item.children" :field="item2.prop"
:title="item2.label" :width="item2.width" :key="index2"
:edit-render="{ name: 'VxeInput', placeholder: '请点击输入...' }"></vxe-column>
</vxe-colgroup>
</template>
</vxe-colgroup>
</vxe-table>
</div>
</div>
</template>
<script setup>
import { reactive, ref, watch } from "vue";
const pointExists = (points, target) => {
for (let i = 0; i < points.length; i++) {
if (points[i][0] === target[0] && points[i][1] === target[1]) {
return true;
}
}
return false;
}
const infoState = reactive({
loading: false,
tableData: [
{
id: 10001,
name: "胜利号1168",
cargoType: "",
shipLook: "",
shipTime: "",
height: "",
jHeight: "",
length: "",
width: "",
xWidth: "",
myType: "夏季吃水",
draft: ""
},
{
id: 10002,
name: "航行方式",
cargoType: "航速",
shipLook: "航次日耗",
shipTime: "航次日耗",
height: "航次日耗",
jHeight: "停泊日耗",
length: "停泊日耗",
width: "停泊日耗",
xWidth: "31",
myType: "热带吃水",
draft: ""
},
{
id: 10003,
name: "航行方式",
cargoType: "航速",
shipLook: "FO(CST180)",
shipTime: "DO(4#)",
height: "GO(0#)",
jHeight: "FO(CST180)",
length: "DO(4#)",
width: "GO(0#)",
xWidth: "31",
myType: "载重吨",
draft: ""
},
{
id: 10004,
name: "设计航速",
cargoType: "",
shipLook: "",
shipTime: "",
height: "",
jHeight: "",
length: "",
width: "",
xWidth: "",
myType: "散装舱容",
draft: ""
},
{
id: 10005,
name: "经济航速",
cargoType: "",
shipLook: "",
shipTime: "",
height: "",
jHeight: "",
length: "",
width: "",
xWidth: "",
myType: "TPC",
draft: ""
},
],
tableList: [
{
label: "船名",
prop: "name",
width: '10%',
},
{
label: "航次",
prop: "hangci",
width: '12%',
},
{
label: "船型",
prop: "shipLook",
width: '10%',
},
{
label: "交船日期",
prop: "shipTime",
width: '10%',
},
{
label: "总吨",
prop: "height",
width: '10%',
},
{
label: "净吨",
prop: "jHeight",
width: '10%',
},
{
label: "总长",
prop: "length",
width: '8%',
},
{
label: "型宽",
prop: "width",
width: '8%',
},
{
label: "其它信息",
prop: "myType",
width: '8%',
},
{
label: "",
prop: "draft",
width: '14%',
},
],
mergeCells: [
{
row: 1,
col: 0,
rowspan: 2,
colspan: 1
},
{
row: 1,
col: 1,
rowspan: 2,
colspan: 1
},
{
row: 1,
col: 2,
rowspan: 1,
colspan: 3
},
{
row: 1,
col: 5,
rowspan: 1,
colspan: 3
},
],
points: [
[0, 0],
[0, 1], [0, 2], [0, 3], [0, 4], [0, 5], [0, 6], [0, 7], [0, 9],
[1, 1], [1, 9],
[2, 9],
[3, 1], [3, 2], [3, 3], [3, 4], [3, 5], [3, 6], [3, 7], [3, 9],
[4, 1], [4, 2], [4, 3], [4, 4], [4, 5], [4, 6], [4, 7], [4, 9],
],
editConfig: {
trigger: 'click',
mode: 'cell',
showIcon: false,
beforeEditMethod: ({ row, rowIndex, column, columnIndex }) => {
const _point = [rowIndex, columnIndex];
return pointExists(infoState.points, _point);
}
},
});
const incomeState = reactive({
loading: false,
isHeader: false,
tableData: [
{
id: 10001,
weikong: "预算",
actualQuantity: "",
cargoVolume: "",
freight: "",
actualQuantity: "",
actualQuantity: "",
actualQuantity: "",
fo_hcrh: "",
do_hcrh: "",
go_hcrh: "",
total: ""
},
],
tableList: [
{
label: "",
prop: "weikong",
width: "10%",
},
{
label: "货量",
prop: "cargoVolume",
width: "10%",
},
{
label: "运费",
prop: "freight",
width: "10%",
},
{
label: "滞期费",
prop: "actualQuantity",
width: "30%",
children: [
{
label: "装港停时",
prop: "fo_hcrh",
width: 180,
},
{
label: "卸港停时",
prop: "do_hcrh",
width: 180,
},
{
label: "滞期费",
prop: "go_hcrh",
width: 180,
},
],
},
{
label: "其它收入",
prop: "actualQuantity",
width: "30%",
children: [
{
label: "亏舱费",
prop: "fo_hcrh",
width: 180,
},
{
label: "",
prop: "do_hcrh",
width: 180,
},
{
label: "",
prop: "go_hcrh",
width: 180,
},
],
},
{
label: "合计",
prop: "total",
width: "12.5%",
},
],
points: [
[0, 0],
[0, 1], [0, 2], [0, 3], [0, 4], [0, 5], [0, 6], [0, 7], [0, 9],
[1, 9],
[2, 9],
[3, 0],
[3, 1], [3, 2], [3, 3], [3, 4], [3, 5], [3, 6], [3, 7], [3, 9],
],
editConfig: {
trigger: 'click',
mode: 'cell',
showIcon: false,
beforeEditMethod: ({ row, rowIndex, column, columnIndex }) => {
console.log('beforeEditMethod>>>', row, rowIndex, column, columnIndex);
const _point = [rowIndex, columnIndex];
return pointExists(incomeState.points, _point);
}
},
});
</script>
<style scoped>
:deep(.vxe-header--row) {
background-color: #def0ff;
&:last-child {
background-color: #f5f9ff;
}
}
.infoState {
height: 400px;
}
.incomeState {
height: 187px;
}
</style>
