引言

在3D开发中，性能优化是区分普通应用和卓越应用的关键。Three.js应用的流畅运行需要60FPS的渲染效率，而移动端设备更面临严格的资源限制。本文将深入解析性能优化核心技术，并通过Vue3实现智能优化系统，助你打造极致流畅的3D体验。

1. 性能核心指标

1.1 关键性能指标(KPI)

1.2 性能瓶颈定位

graph TD
    A[性能问题] --> B{帧率低？}
    A --> C{卡顿？}
    A --> D{内存高？}
    B --> E[CPU瓶颈]
    B --> F[GPU瓶颈]
    C --> G[主线程阻塞]
    D --> H[资源泄露]

2. 几何体优化

2.1 几何体合并(BufferGeometryUtils)

<script setup>
import { mergeBufferGeometries } from 'three/addons/utils/BufferGeometryUtils.js';

// 创建多个相同材质的几何体
const geometries = [];
for (let i = 0; i < 100; i++) {
  const geometry = new THREE.BoxGeometry(1, 1, 1);
  geometry.translate(Math.random()*10, Math.random()*10, Math.random()*10);
  geometries.push(geometry);
}

// 合并为单个几何体
const mergedGeometry = mergeBufferGeometries(geometries);
const mesh = new THREE.Mesh(mergedGeometry, material);
scene.add(mesh);

console.log('Draw Calls 从 100 降为 1');
</script>

2.2 实例化渲染(InstancedMesh)

const geometry = new THREE.BoxGeometry(1, 1, 1);
const material = new THREE.MeshStandardMaterial();
const instances = new THREE.InstancedMesh(geometry, material, 1000);

// 设置实例位置和旋转
const matrix = new THREE.Matrix4();
for (let i = 0; i < 1000; i++) {
  matrix.setPosition(
    Math.random() * 100 - 50,
    Math.random() * 100 - 50,
    Math.random() * 100 - 50
  );
  instances.setMatrixAt(i, matrix);
}

scene.add(instances);

2.3 层级细节(LOD)

<script setup>
import { LOD } from 'three';

// 创建不同细节级别的模型
const highDetail = new THREE.Mesh(highDetailGeo, material);
const midDetail = new THREE.Mesh(midDetailGeo, material);
const lowDetail = new THREE.Mesh(lowDetailGeo, material);

// 创建LOD对象
const lod = new LOD();
lod.addLevel(highDetail, 0);    // 距离0-20单位使用高模
lod.addLevel(midDetail, 20);    // 20-50单位使用中模
lod.addLevel(lowDetail, 50);    // >50单位使用低模

scene.add(lod);

// 每帧更新
function updateLOD() {
  lod.update(camera);
}
</script>

3. 材质与纹理优化

3.1 纹理压缩技术

// 使用Basis Universal压缩纹理
import { BasisTextureLoader } from 'three/addons/loaders/BasisTextureLoader.js';

const basisLoader = new BasisTextureLoader();
basisLoader.setTranscoderPath('libs/basis/');
basisLoader.load('textures/rock.basis', (texture) => {
  texture.encoding = THREE.sRGBEncoding;
  material.map = texture;

  console.log('纹理大小:',
    (texture.source.data.byteLength / 1024).toFixed(2) + 'KB');
});

3.2 共享材质

const materialCache = {};

function getMaterial(color) {
  if (!materialCache[color]) {
    materialCache[color] = new THREE.MeshStandardMaterial({ color });
  }
  return materialCache[color];
}

// 场景中使用
objects.forEach(obj => {
  obj.material = getMaterial(obj.color);
});

3.3 材质优化策略

4. 光照与阴影优化

4.1 光照烘焙

// 使用Blender烘焙光照贴图
const bakedTexture = textureLoader.load('baked/lightmap.jpg');
bakedTexture.flipY = false;

const bakedMaterial = new THREE.MeshBasicMaterial({
  map: diffuseTexture,
  lightMap: bakedTexture,
  lightMapIntensity: 1.5
});

staticObjects.forEach(obj => {
  obj.material = bakedMaterial;
  obj.receiveShadow = false; // 禁用实时阴影
});

4.2 动态光源限制

// 只保留最重要的光源
scene.lights.sort((a, b) => b.intensity - a.intensity);
scene.lights.slice(3).forEach(light => {
  light.visible = false;
});

// 动态光源剔除
function updateLights() {
  scene.lights.forEach(light => {
    light.visible = camera.frustumIntersectsSphere(light.boundingSphere);
  });
}

4.3 阴影优化

// 光源配置
directionalLight.shadow.mapSize.width = 1024;
directionalLight.shadow.mapSize.height = 1024;
directionalLight.shadow.camera.near = 0.5;
directionalLight.shadow.camera.far = 50;
directionalLight.shadow.radius = 2; // PCF软阴影

// 渲染器配置
renderer.shadowMap.type = THREE.PCFSoftShadowMap;
renderer.shadowMap.enabled = true;

5. 渲染优化技术

5.1 视锥剔除(Frustum Culling)

const frustum = new THREE.Frustum();
const viewProjectionMatrix = new THREE.Matrix4();

function updateCulling() {
  viewProjectionMatrix.multiplyMatrices(
    camera.projectionMatrix,
    camera.matrixWorldInverse
  );
  frustum.setFromProjectionMatrix(viewProjectionMatrix);

  scene.children.forEach(obj => {
    if (obj.isMesh) {
      obj.visible = frustum.intersectsObject(obj);
    }
  });
}

5.2 遮挡剔除(Occlusion Culling)

// 使用Hi-Z遮挡剔除
import { Occlusion } from 'three/addons/objects/Occlusion.js';

const occlusion = new Occlusion(renderer, camera);
occlusion.enabled = true;

function render() {
  occlusion.update();
  renderer.render(scene, camera);
}

5.3 渲染目标降级

// 动态调整分辨率
function adjustResolution() {
  const scale = Math.min(1, 16 / stats.fps); // FPS<16时降级
  renderer.setSize(window.innerWidth * scale, window.innerHeight * scale);

  // 移动端优化
  if (isMobile) {
    renderer.setPixelRatio(Math.min(1, window.devicePixelRatio));
  }
}

6. 多线程计算

6.1 Web Worker物理计算

// 主线程
const physicsWorker = new Worker('physics-worker.js');

function updatePhysics() {
  physicsWorker.postMessage({
    type: 'step',
    dt: clock.getDelta(),
    positions: getObjectPositions()
  });

  physicsWorker.onmessage = (e) => {
    applyPhysicsResults(e.data);
  };
}

// physics-worker.js
self.onmessage = (e) => {
  if (e.data.type === 'step') {
    // 执行物理计算
    world.step(e.data.dt);

    // 返回结果
    postMessage(getPhysicsResults());
  }
};

6.2 OffscreenCanvas渲染

// 主线程
const offscreenCanvas = canvas.transferControlToOffscreen();
const worker = new Worker('render-worker.js');

worker.postMessage({
  canvas: offscreenCanvas,
  width: canvas.width,
  height: canvas.height
}, [offscreenCanvas]);

// render-worker.js
self.onmessage = (e) => {
  const { canvas, width, height } = e.data;

  // 在Worker中初始化Three.js
  const renderer = new THREE.WebGLRenderer({ canvas });
  renderer.setSize(width, height);

  // 创建场景、相机等...

  function animate() {
    requestAnimationFrame(animate);
    renderer.render(scene, camera);
  }
  animate();
};

7. Vue3智能优化系统

7.1 项目结构

src/
  ├── modules/
  │    ├── performance/
  │    │    ├── Optimizer.js       // 优化策略引擎
  │    │    ├── MonitorPanel.vue   // 性能监控面板
  │    │    └── AutoOptimizer.vue  // 自动优化组件
  └── App.vue

7.2 优化策略引擎

// Optimizer.js
class PerformanceOptimizer {
  constructor(scene, camera, renderer) {
    this.scene = scene;
    this.camera = camera;
    this.renderer = renderer;
    this.stats = new Stats();
    this.optimizationLevel = 0; // 0-3
    this.strategies = [
      this.lowLevelStrategies,
      this.mediumLevelStrategies,
      this.highLevelStrategies
    ];
  }

  lowLevelStrategies() {
    // 基础优化
    renderer.shadowMap.enabled = false;
    scene.traverse(obj => {
      if (obj.material) obj.material.roughness = 1;
    });
  }

  mediumLevelStrategies() {
    // 中级优化
    renderer.setPixelRatio(1);
    this.applyLODs();
  }

  highLevelStrategies() {
    // 高级优化
    this.mergeStaticGeometries();
    this.disableUnseenLights();
  }

  applyOptimization(level) {
    // 重置所有优化
    this.resetOptimizations();

    // 应用新级别优化
    for (let i = 0; i < level; i++) {
      this.strategies[i].call(this);
    }

    this.optimizationLevel = level;
  }

  autoOptimize() {
    const fps = this.stats.getFps();

    if (fps < 30 && this.optimizationLevel < 3) {
      this.applyOptimization(this.optimizationLevel + 1);
    } else if (fps > 50 && this.optimizationLevel > 0) {
      this.applyOptimization(this.optimizationLevel - 1);
    }
  }
}

7.3 性能监控面板

<!-- MonitorPanel.vue -->
<template>
  <div class="monitor-panel">
    <div class="fps-meter">
      <h3>FPS: {{ stats.fps.toFixed(1) }}</h3>
      <div class="graph">
        <div v-for="(val, i) in fpsHistory"
             :key="i"
             class="bar"
             :style="`height: ${Math.min(100, val)}%`"
             :class="{ danger: val < 30 }">
        </div>
      </div>
    </div>

    <div class="stats-grid">
      <div class="stat">
        <span class="label">Draw Calls</span>
        <span class="value" :class="{ warn: renderStats.calls > 100 }">
          {{ renderStats.calls }}
        </span>
      </div>
      <!-- 其他指标... -->
    </div>

    <div class="optimization-control">
      <h4>优化级别: {{ levelNames[optimizer.level] }}</h4>
      <button v-for="(name, level) in levelNames"
              :class="{ active: optimizer.level === level }"
              @click="optimizer.applyOptimization(level)">
        {{ name }}
      </button>
    </div>
  </div>
</template>

<script setup>
import { ref, reactive, onMounted } from 'vue';

const props = defineProps(['optimizer']);
const stats = reactive({ fps: 0, memory: 0 });
const fpsHistory = ref([]);
const levelNames = ['关闭', '低', '中', '高'];

onMounted(() => {
  setInterval(() => {
    stats.fps = props.optimizer.stats.getFps();
    stats.memory = performance.memory.usedJSHeapSize / 1024 / 1024;

    // 更新FPS历史
    fpsHistory.value.push(stats.fps);
    if (fpsHistory.value.length > 60) {
      fpsHistory.value.shift();
    }
  }, 1000);
});
</script>

7.4 自动优化组件

<!-- AutoOptimizer.vue -->
<script setup>
import { onMounted, onUnmounted } from 'vue';
import { Optimizer } from './Optimizer';

const props = defineProps(['scene', 'camera', 'renderer']);
const optimizer = ref(null);

onMounted(() => {
  optimizer.value = new Optimizer(
    props.scene,
    props.camera,
    props.renderer
  );

  // 每5秒检测一次
  const interval = setInterval(() => {
    optimizer.value.autoOptimize();
  }, 5000);

  onUnmounted(() => clearInterval(interval));
});

defineExpose({
  optimizer
});
</script>

<template>
  <div v-if="optimizer">
    <MonitorPanel :optimizer="optimizer" />
  </div>
</template>

7.5 应用集成

<!-- App.vue -->
<script setup>
import { ref } from 'vue';
import * as THREE from 'three';
import AutoOptimizer from './modules/performance/AutoOptimizer.vue';

// 初始化场景
const scene = new THREE.Scene();
const camera = new THREE.PerspectiveCamera();
const renderer = new THREE.WebGLRenderer();

// 创建测试场景
function createTestScene() {
  // 添加大量物体测试性能...
}

createTestScene();

// 提供优化器引用
const optimizerRef = ref(null);

// 手动触发优化
function applyMaxOptimization() {
  optimizerRef.value.optimizer.applyOptimization(3);
}
</script>

<template>
  <div class="app">
    <canvas ref="canvasRef"></canvas>
    <AutoOptimizer
      ref="optimizerRef"
      :scene="scene"
      :camera="camera"
      :renderer="renderer"
    />
    <button @click="applyMaxOptimization">极限优化</button>
  </div>
</template>

8. 移动端专项优化

8.1 触控优化策略

// 降低渲染分辨率
if (isMobile) {
  renderer.setPixelRatio(Math.min(1.5, window.devicePixelRatio));
}

// 简化交互
const raycaster = new THREE.Raycaster();
raycaster.params.Points.threshold = 0.1; // 增加拾取阈值

// 禁用高开销特效
renderer.shadowMap.enabled = false;
material.aoMap = null;

8.2 功耗控制

// 帧率限制
let lastRender = 0;
const targetFPS = 30;

function animate(timestamp) {
  if (timestamp - lastRender > 1000 / targetFPS) {
    renderer.render(scene, camera);
    lastRender = timestamp;
  }
  requestAnimationFrame(animate);
}

// 后台暂停
document.addEventListener('visibilitychange', () => {
  if (document.hidden) {
    cancelAnimationFrame(animationId);
  } else {
    animationId = requestAnimationFrame(animate);
  }
});

8.3 热力性能分析

9. 性能优化路线图

10. 常见问题解答

Q1：Draw Call过高如何定位？

// 打印Draw Call分布
console.log('Draw Call分布:');
scene.traverse(obj => {
  if (obj.isMesh) {
    console.log(`${obj.name}: ${obj.geometry.drawcalls}`);
  }
});

// 优化建议：
// - 相同材质的物体使用mergeBufferGeometries合并
// - 动态物体使用InstancedMesh

Q2：内存泄露如何排查？

// 内存泄露检测工具
function setupLeakDetection() {
  const objects = new Set();

  return {
    track(obj) {
      objects.add(obj);
      return obj;
    },
    report() {
      console.log(`当前跟踪对象数: ${objects.size}`);
      console.log('未释放对象:', Array.from(objects));
    }
  };
}

// 使用示例
const leakDetector = setupLeakDetection();
scene.add(leakDetector.track(new THREE.Mesh(geometry, material)));

Q3：移动端卡顿如何紧急优化？

1. 立即降低分辨率：renderer.setSize(width/2, height/2)
2. 禁用所有阴影：renderer.shadowMap.enabled = false
3. 切换为简单材质：material = new THREE.MeshBasicMaterial()
4. 降低帧率目标：targetFPS = 30

11. 总结

通过本文，你已掌握：

1. 性能核心指标与瓶颈定位
2. 几何体优化：合并、实例化、LOD
3. 材质纹理压缩与复用技术
4. 光照烘焙与动态光源优化
5. 高级渲染技术：视锥剔除、遮挡剔除
6. Web Worker多线程计算
7. Vue3智能优化系统实现
8. 移动端专项优化策略

关键洞察：性能优化是平衡艺术与科学的过程，Three.js优化核心在于减少GPU负载（Draw Call/纹理）和CPU计算（物理/逻辑），通过层级优化策略实现60FPS的流畅体验。

下一篇预告

第十一篇：加载外部模型：GLTF/OBJ格式解析
你将学习：

• GLTF格式结构与优势
• OBJ/MTL传统格式处理
• 模型加载进度管理
• 模型优化与压缩技术
• 骨骼动画加载与控制
• 模型错误处理与回退
• Vue3实现模型预览编辑器

准备好将专业3D模型融入你的应用了吗？让我们揭开三维资产导入的神秘面纱！
